| Place of Origin: | ce/ul/kc/msds/un38.3 |
|---|---|
| Brand Name: | HHS |
| Certification: | ce/ul/kc/msds/un38.3 |
| Model Number: | 26650 |
| Minimum Order Quantity: | 100 |
| Price: | 0.99-1.99 |
| Packaging Details: | Cartons, Pallets |
| Delivery Time: | 5-15 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000pcs per month |
| Type: | LiFePO4 | Cycle Life: | 2000 Times |
|---|---|---|---|
| Warranty: | 12 Months | Nominal Capacity: | 3.2Ah |
| Shape: | Cylindrical | Quality: | Grade AAA |
| High Light: | 26650 LiFePO4 Cell,3.2V 26650 LiFePO4 Cell,26650 LiFePO4 Battery Cell |
||
Cylindrical 3.2V 3.2ah 26650 LiFePO4 Battery Cell Lighter Weight
Approval Cylindrical 26650 Battery Rechargeable 3.2V 3.2ah LiFePO4 Battery Cell
Features
Using the technology of lithium iron phosphate cell, superior safety, thousands of cycles, 100%DOD, under normal conditions
Built-in automatic protection for over-charge, over discharge, over current and over temperature
Maintenance free
Internal cell balancing
Lighter weight: About 40% ~50% of the weight of a comparable lead acid battery.
Can be charged using most standard lead-acid charges (set)
Wider temperature range:-20ºC~60ºC
Support for serial application expansion (up to 51.2V)
Product Description
| # | Item | General Parameter | Remark | ||
| 1 | Rated Capacity | Typical | 3000mAh | Standard discharge(0.5C) after standard charge | |
| Minimum | 2950mAh | ||||
| 2 | Nominal Voltage | 3.2V | Mean Operation Voltage | ||
| 3 | Voltage at end of Discharge | 2.0V | Discharge Cut-off Voltage | ||
| 4 | Charging at end of Voltage | 3.65V | |||
| 5 | Internal Impedance | 30m | Internal resistance measured at AC 1kHz after 50% charge The measure must uses the new battreies that within one week after shipment and cycles no more that 5 times |
||
| 6 | Standard charge | Constant Current 0.5C Constant Voltage 3.65V 0.01C cut-off | Charge time:Approx 4.0h | ||
| 7 | Standard discharge | Constant Current 0.5C end Voltage 2.0V | |||
| 8 | Fast charge | Constant Current 1C Constant Voltage 3.65V 0.01C cut-off | Charge time:Approx 2.5h | ||
| 9 | Fast discharge | Constant Current 1C end Voltage 2.0V | |||
| 10 | Maximum Continuous Charge Current | 1C | |||
Q: What Is The Minimum Order Quantity(MOQ)?
A: MOQ is :100pcs .Or Depends On Your Inquiries.Sample Can Send To Tested At Fisrt
Q: Can I Print LOGO Or With Customzied Packaging ?
A:Yes, We Can Print Customized Logo If Order Quantity Is Above 1000pcs.(Logo Color Less Than 2 colors )
Q: How Long Is The Lead Time?
A: Small Quantity: 2-7 Working Days - Since Deposit Received Or Design Confirmed. Large quantity: 7-30 Working Days - Since Deposit Received Or Design Confirmed.
Q: Is there Any Warranty Or After-Sale Service?
A: Free Replacement Against Shipping damage. 24 Hours Customer Services.
