12V 100Ah LiFePO4 Storage Battery 21700 Electric Car Battery Pack

Basic Information
Place of Origin: China
Brand Name: HHS
Certification: CE
Model Number: HHS-L
Minimum Order Quantity: 100 - 4999 Pieces
Price: $168- $399
Packaging Details: 1. Standard package for bluetooth headset battery 2. Special package for bluetooth headset battery
Delivery Time: 5-8 work days
Payment Terms: L/C, T/T
Supply Ability: 5000pcs per month
Detail Information
Optional: RS485 /RS232 / CANBUS Application: Home Appliances, BOATS, Golf Carts
Dimension: 483*170*241mm / Customized Nominal Capacity: 24Ah
Charging Voltage: 14.6V, 3.7volt Weight: 25kg
High Light:

100Ah LiFePO4 Storage Battery

,

21700 Electric Car Battery Pack

,

12V 100Ah Lithium Lifepo4 Battery


Product Description

12V 100Ah LiFePO4 Storage Battery 21700 Electric Car Battery Pack



Factory Price 12V 100Ah Lifepo4 Battery 21700 Electric Car Battery Pack



Description of Lithium Lifepo4 Battery

LiFePO4 battery has no memory effects and highly efficient charge: lithium iron phosphate batteries do not have memory effect, no matter what state the battery is on, it can be charged or used at any time, no need to charge it under the situation of fully discharged. Besides, lithium iron phosphate battery can be high current 2C fast charged and discharged, under the special charger ,1.5C charge can make the battery full of capacity within 40 minutes, the starting current can reach 2 C, and the lead acid battery does not have this performance at present.



Electrical
Characteristics
Nominal Voltage 12.8V
Nominal Capacity 200Ah@0.2C
Energy 2560Wh
Internal Resistance ≤35mΩ
Cycle Life 2000 Cycles @ 0.2C Charging/Discharging ,Until 70% Capacity
Self Discharge ≤3.5% per month at 25℃
Standard Charging Max.Charging Voltage 14.0~14.6V
Charging Mode At 0℃~45℃ temperature, charged to 14.6V at a constant current of 0.2C, and then,changed continuously with constant voltage of 14.6V until the current was not more than 0.02C
Charging Current 100A
Max.Charging Current 100A
Standard Discharging Discharging Current 150A
Max. Continuous Current 150A
Max.Pulse Current 300A(<3S)
Discharging Cut-off Voltage 10.0
Operating Condition Charge Temperature 0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
Discharge Temperature -20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity
Storage Temperature 0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
Water Dust Resistance IP55
Structure Cell & Format IFR32700 N60,4S33P
Casing Plastic
Dimension(L*W*H*TH) 522*238*217*217
Weight Approx. 23.5Kg
Terminal M8

12V 100Ah LiFePO4 Storage Battery 21700 Electric Car Battery Pack 0.

12V 100Ah LiFePO4 Storage Battery 21700 Electric Car Battery Pack 1

12V 100Ah LiFePO4 Storage Battery 21700 Electric Car Battery Pack 2



FAQ:



Q1. What is the biggest difference between your battery and supplier:

A: Safest with longer lifespan.



Q2. How about your Lithium Lifepo4 Battery delivery time?

A: 1-25 workdays after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.



Q3: How about your warranty?

A: 3years warranty



Q4. Is this Lithium LiFePO4 Battery safe?

A: Passed the overcharge, over discharge, over temperature, short circuit, acupuncture and other safety tests, no fire, no explosion at any circumstance; price to ensure our customers benefit
